General

• General planning

• Converter list

• Project meetings
  • LIU day - 1st December 2010
  • Chamonix 2011
  • SY-EPC Projects Meeting 26 March 2010 , 6 september 2011
  • LIU-PS Projects Meeting 10 June 2014
  • LIU and TE/EPC activities 2 May 2016, 10 August 2016, 8 February 2017

• 2010 MD results and implications for the PS upgrade

• Integration and ECR progress
  SY-EPC equipment integration process

Manufacture and commission PI.SMH42 Power Converter

LIU-PS 5 WU 104255 PLAN 10349	Workunit holder: Todor Todorcevic Budget Code: 99270 Due date: October 2019
Circuits	RPMXA.365.PI.RSMH42
Deliverables	1+1 MarXDisCap Converters
Documentation	Functional specification , ECR Magnet functional specification , engineering specification WIC engineering specification Injection presentation TE-ABT 2010 Septum and bumpers requirementsSY-EPC 2011 PS injection septa for 2 GeV proton injection review
Installation data	Bdg. 365 - Room R-004 ? racks Width: ?mm, Depth: ?mm, Height: xmm, Weight: xkg Installation Procedure

Manufacture and commission PI.BSM42 Power Converter

LIU-PS 5.1 WU 104266 PLAN 10350	Workunit holder: Jean-Marc Cravero Budget Code: 99274 Due date: October 2019
Circuits	RPAGG.365.PI.RBSW42
Deliverables	1 SIRIUS_FP2P2S Converters
Documentation	Functional specification , ECR Magnet specification WIC engineering specification Injection presentation TE-ABT 2010 Septum and bumpers requirementsSY-EPC 2011 PS injection septa for 2 GeV proton injection review
Installation data	Bdg. 365 - Room R-004 2 racks Width: 3000 mm, Depth: 900 mm, Height: 2050 mm, Weight: 2000 kg Installation Procedure

Upgrade and commission PI.BSM40, 41, 43 & 44 Power Converters

LIU-PS 5.1 WU 104257 PLAN 10351	Workunit holder: Jean-Marc Cravero Budget Code: 99275 Due date: October 2019
Circuits	RPAGF.365.PI.RBSW40, RPAGF.365.PI.RBSW41, RPAGF.365.PI.RBSW43, RPAGF.365.PI.RBSW44
Deliverables	4+1 FP2P2S Converters
Documentation	Functional specification , ECR Magnet functional specification , design report WIC engineering specification Injection presentation TE-ABT 2010 Septum and bumpers requirements SY-EPC 2011 Meeting on conventional injection bumpers March 2017 Magnet Design Report
Installation data	Bdg. 365 - Room R-004 racks Width: 1800 mm, Depth: 900 mm, Height: 2050 mm, Weight: 1000 kg Installation Procedure

Manufacture and commission PS injection low beta quadrupoles Power Converters

LIU-PS 5 WU 113121 PLAN 10352	Workunit holder: Jean-Marc Cravero Budget Code: 99269 Due date: October 2019
Circuits	RPAFN.365.PI.RQLB
Deliverables	1+1 modified MaxiDisCap Converters
Documentation	Functional specification , ECR Magnet (PXMQNCHAWP) design report (SS33 and SS49 in series). WIC engineering specification
Installation data	Bdg. 365-R-004 1 rack Width: 600 mm, Depth: 900 mm, Height: 2050 mm, Weight: 250 kg Installation Procedure

Manufacture and commission IPM magnet Power Converters

LIU-PS 5 WU 162344 PLAN 11110	Workunit holder: Gilles le Godec Budget Code: 99268 Due date: October 2019
Circuits	RPAEK.355.PR.RBGI84MAIN, RPAEK.355.PR.RBGI84TRIM
Deliverables	2+0 SIRIUS 2P Converter for the vertical IPM
Documentation	Functional specification , ECR Status of the Beam Gas Ionisation (BGI) profile monitor for the PS (2015) Plans for the vertical BGI (2018) Magnet
Installation data	355-R-003 Magnet in SS84 Installation Procedure

PS Power Converters Installation

LIU-PS 5 WU 202216 PLAN 10349, 10350, 10351, 10352, 11110	Workunit holder: Christophe Coupat Budget Code: 68814 Due date: April 2020
Deliverables	Installation for WUs: 104255 PI.SMH42 Power Converter 104266 PI.BSM42 Power Converter 104257 PI.BSM40, 41, 43 & 44 Power Converters 113121 PS injection low beta quadrupoles Power Converters 162344 IPM magnet Power Converters
Installation data	365-R-004, 355-R-003

TT2 transfer line

LIU-TT2-NT 6.1 WU 170703 , 170704 , 170705 PLAN 11169, 10329	Workunit holder: Konstantinos Papastergiou Budget Code: 99639 Due date: January 2019
Circuits	TT2: F16.RQFO105, F16.RBHZ117, F16.RQDE120, F16.RBVT123, F16.RQFO135, F16.RBHZ147, F16.RQDE150, F16.RQDE163, F16.RQFO165, F16.RBHZ 167, F16.RBVT173, F16.RQDE180, F16.RQFO205, F16.RQDE207, F16.RQDE210, F16.RQDE213, F16.RQFN215, F16.RQDE217, F16.RQDE220, F16.RQDE280, F16.RQFO225, F16.RQFO265, F16.RQFO325, F16.RBTI247, F16.RDHZ327, F16.RQFO 375, F16.RBHZ377, F16.RBHZ378. n_TOF: FTN.RBHZ403S, FTN.RBHZ409S, FTN.RBHZ459S, FTN.RQFO415S, FTN.RQDE430S.
Deliverables	22+0 SIRIUS Converters 5+1 SIRIUS 2P Converters 6+1 SIRIUS 4P Converters
Documentation	Functional Specification general 2014 , Sirius S , Sirius 2P , Sirius 4P , Sirius 4P+. ECR bdg.250 , bdg.269 Consolidation work unit description TT2 , n_TOF Infrastructure Requirements Specification Magnet
Installation data	building 269 Installation Procedure , False floor specification

LIU-TT2-NT 6.2 WU 170706 PLAN 10329	Workunit holder: Serge Pittet Budget Code: 99639 Due date: January 2019
Circuits	TT2: F16.RDHZ337, F16.RDVT353, F16.RSNP208, F16.RUES228. n_TOF: FTN.RDHZ436, FTN.RDVT451.
Deliverables	4+1 CANCUN_50 Converters. 2+1 COMBO Converters for the F16.RSNP208 and F16.RUES228.
Documentation	Functional Specification general 2014 , CANCUN , COMBO. ECR bdg.269 Consolidation work unit description TT2 , n_TOF Infrastructure Requirements Specification Magnet
Installation data	building 269 Installation Procedure CANCUN , COMBO.

TT2 Converters Installation

LIU-TT2-NT 1.1	Workunit holder: James Devine Budget Code: 51261 Due date: December 2019
Deliverables	ME24 substation upgrade - AC cables

LIU-TT2-NT 1.2	Workunit holder: Patrick Lelong Budget Code: 51262 Due date: December 2019
Deliverables	DC cabling modifications, existing and new

LIU-TT2-NT 2.1	Workunit holder: Caterina Bertone Budget Code: 53325 Due date: December 2019
Deliverables	Handling and transport consumables for TT2 consolidation affected to PS-LIU

LIU-TT2-NT 3.1	Workunit holder: Serge Deleval Budget Code: 53692 Due date: December 2019
Deliverables	Cooling for the new power converter inside the bldg 269

LIU-TT2-NT 3.2	Workunit holder: Serge Deleval Budget Code: 53692 Due date: December 2019
Deliverables	Replacement of the ventilation system for the bldg 269

LIU-TT2-NT 4.1 WU 170780	Workunit holder: Dominique Bodart Budget Code: 99399 Due date: December 2019
Deliverables	Replacement magnet BHZ377 and 378

LIU-TT2-NT 5.1 WU 170690	Workunit holder: Richard Mompo Budget Code: 98470 Due date: December 2019
Deliverables	WIC for TT2 and nTOF

LIU-TT2-NT 6.1 WU 170703	Workunit holder: Konstantinos Papastergiou Budget Code: 99639 Due date: December 2019
Deliverables	Metallic support structure installed Fire detection system

Manufacture and commission Chromaticity Sextupoles Power Converter

LIU-PS 5 WU 113114 PLAN 10347	Workunit holder: Gilles Le Godec Budget Code: 99263 Due date: March 2015
Circuits	RPADH.355.PR.RXNO60
Deliverables	1 APOLO_2s Converters
Documentation	Functional specification Magnet WIC engineering specification
Installation data	bdg. 355 Width: 1800 mm, Depth: 900 mm, Height: 2300 mm, Weight: 2000 kg Installation Procedure

Manufacture and commission High Energy Dipoles Power Converter

LIU-PS 5 WU 127999 PLAN 10348	Workunit holder: Gilles Le Godec Budget Code: 99263 Due date: July 2015
Circuits	RPADJ.365.PR.RXNO55
Deliverables	1 COMET Converters
Documentation	Functional specification Magnet (PXMXNBAFWP) WIC engineering specification
Installation data	bdg. 365, 1 racks Width: 800 mm, Depth: 900 mm, Height: 2300 mm, Weight: 1600 kg Installation Procedure

Manufacture and commission Low Energy Quadrupoles (QN&QSK) Power Converters

LIU-PS 5.2 WU 104258 PLAN 10353 (QN), 10354 (QSK)	Workunit holder: Serge Pittet Budget Code: 99268 Due date: February 2016 (QN), March 2017 (QSK)
Circuits	PR.RQDN00, PR.RQDW06, PR.RQDN10, PR.RQDW18, PR.RQDW22, PR.RQDW28, PR.RQDW32, PR.RQDN36, PR.RQDN40, PR.RQDN46, PR.RQDN50, PR.RQDW56, PR.RQDW60, PR.RQDN68, PR.RQDN72, PR.RQDN78, PR.RQDN82, PR.RQDN90, PR.RQDN86, PR.RQDN96, PR.RQFN05, PR.RQFN09, PR.RQFW17, PR.RQFN21, PR.RQFW27, PR.RQFW31, PR.RQFN35, PR.RQFN39, PR.RQFN45, PR.RQFN49, PR.RQFN55, PR.RQFW59, PR.RQFN67, PR.RQFN71, PR.RQFN77, PR.RQFN81, PR.RQFN85, PR.RQFN89, PR.RQFN95, PR.RQFN99, PR.RQSK03, PR.RQSK04, PR.RQSK07, PR.RQSK08, PR.RQSK19, PR.RQSK20, PR.RQSK23, PR.RQSK24, PR.RQSK29, PR.RQSK30, PR.RQSK33, PR.RQSK34, PR.RQSK37, PR.RQSK38, PR.RQSK41, PR.RQSK42, PR.RQSK43, PR.RQSK44, PR.RQSK47, PR.RQSK48, PR.RQSK53, PR.RQSK54, PR.RQSK57, PR.RQSK58, PR.RQSK69, PR.RQSK70, PR.RQSK73, PR.RQSK74, PR.RQSK79, PR.RQSK80, PR.RQSK83, PR.RQSK84, PR.RQSK87, PR.RQSK88, PR.RQSK91, PR.RQSK92, PR.RQSK93, PR.RQSK94, PR.RQSK97, PR.RQSK98
Deliverables	80+4 CANCUN_20 Converters
Documentation	Summary of the Requirements for LIU-PS Low-Energy Magnets QN Functional specification QSK and DVT Functional specification , ECR OP Shutdown Lectures, 10/02/2016 MU41 & MU42 ECR (QSK42 goes to SS52) Magnet QFN, QDN (PXMQNAAIAP) Magnet QFW, QDW (PXMQNABIAP) Magnet QSK (PXMM_AAIAP and PXMQSAAIAP)
Installation data	355/R-005 7 racks HCRYSTE001 (max 6 converters/rack) for the QN in December 2015 7 racks HCRYSTE001 (max 6 converters/rack) for the QSK in January 2017 Width: 600mm, Depth: 900mm, Height: 42U, Weight: 240kg 2 closed control racks for ethernet switches and pulse injectors Installation Procedure QN: Installation Data, DIC ether, DIC dc QSK: Installation Data, DIC ether

Manufacture and commission Low Energy Dipoles (DHZ&DVT) Power Converters

LIU-PS 5.3 WU 104264 PLAN 10355	Workunit holder: Serge Pittet Budget Code: 99268 Due date: March 2017
Circuits	PR.RDHZ01, PR.RDHZ03, PR.RDHZ05, PR.RDHZ07, PR.RDHZ09, PR.RDHZ11, PR.RDHZ13, PR.RDHZ15, PR.RDHZ17, PR.RDHZ19, PR.RDHZ21, PR.RDHZ23, PR.RDHZ25, PR.RDHZ27, PR.RDHZ29, PR.RDHZ31, PR.RDHZ33, PR.RDHZ35, PR.RDHZ37, PR.RDHZ39, PR.RDHZ41, PR.RDHZ43, PR.RDHZ45, PR.RDHZ47, PR.RDHZ49, PR.RDHZ51, PR.RDHZ53, PR.RDHZ55, PR.RDHZ57, PR.RDHZ59, PR.RDHZ61, PR.RDHZ63, PR.RDHZ65, PR.RDHZ67, PR.RDHZ69, PR.RDHZ71, PR.RDHZ73, PR.RDHZ75, PR.RDHZ77, PR.RDHZ79, PR.RDHZ81, PR.RDHZ83, PR.RDHZ85, PR.RDHZ87, PR.RDHZ89, PR.RDHZ91, PR.RDHZ93, PR.RDHZ95, PR.RDHZ97, PR.RDHZ99, PR.RDVT02, PR.RDVT04, PR.RDVT08, PR.RDVT12, PR.RDVT20, PR.RDVT22, PR.RDVT24, PR.RDVT30, PR.RDVT34, PR.RDVT38, PR.RDVT44, PR.RDVT54, PR.RDVT64, PR.RDVT70, PR.RDVT74, PR.RDVT76, PR.RDVT80, PR.RDVT88, PR.RDVT94, PR.RDVT98
Deliverables	70+5 CANCUN_20 Converters
Documentation	Summary of the Requirements for LIU-PS Low-Energy Magnets DHZ Functional specification , ECR QSK and DVT Functional specification , ECR Magnet DHZ in main units Magnet DVT (PXMM_AAIAP and PXMCVAAWAP)
Installation data	DHZ: 368/R-003 9 racks HCRYSTE001 (max 6 converters/rack) Width: 600mm, Depth: 900mm, Height: 42U, Weight: 240kg 1 closed control racks for ethernet switches and pulse injectors Existing patch panel will be removed and DC cables directly connected to the racks DVT: 355/R-005 3 racks HCRYSTE001 (max 6 converters/rack) Width: 600mm, Depth: 900mm, Height: 42U, Weight: 240kg 1 closed control racks for ethernet switches and pulse injectors Installation Procedure Installation Data, DIC ether DHZ, DIC ether DVT

Manufacture and commission Skew sextupoles Power Converters

LIU-PS 5.3 NA	Workunit holder: Serge Pittet Budget Code: 99268 Due date: May 2014
Circuits	PR.RXSK10, PR.RXSK14, PR.RXSK52, PR.RXSK58
Deliverables	4+1 CANCUN_50 Converters
Documentation	Magnet 601(PXMX_AAIAP) Magnet 602(PXMX_ABIAP)
Installation data	1 rack HCRYSTE001 (max 6 converters/rack) Width: 600mm, Depth: 900mm, Height: 42U, Weight: 240kg 1 closed control racks for ethernet switches and pulse injectors Installation Procedure

Manufacture and commission IPM magnet Power Converters

LIU-PS 5 WU 162143 PLAN 10356	Workunit holder: Yves Thurel Budget Code: 99268 Due date: June 2016
Circuits	RPACY.355.PR.RBGI82MAIN, RPACY.355.PR.RBGI82TRIM
Deliverables	2+0 cobalt Converter for the horizontal IPM
Documentation	Project mandate, Milestone plan Functional specification Status of the Beam Gas Ionisation (BGI) profile monitor for the PS Magnet ECR , modification ECR WIC engineering specification
Installation data	355-R-005, rack PR41 1 rack Width: 600mm, Depth: 900mm, Height: 42U, Weight: 240kg 1 closed control racks for ethernet switches and pulse injectors Installation Procedure

Not upgraded converters

Confirmed during LIU PS meeting 115

Injection PS

• PI.BSW26, PI.SMH26

Ring PS

• PR.ECLOUD-D98, PR.ECLOUD-CE98,
  PR.QTRJ-DB-A, PR.QTRJ-DB-B, PR.QTRJ-TR-A, PR.QTRJ-TR-B
  RPOPS.367.PR.MPC, RPSFT.358.PR.MPS,
  PR.W8L, PR.WFNI, PR.WFNP, PR.WDNI, PR.WDNP, PR.WFW, PR.WDW, PR.WLB8L,
  PR.DHZ05-OC, PR.DHZ18-OC, PR.DHZ60-OC,
  PR.XSE, PR.QSE
  PR.ODN, PR.ONO39, PR.ONO55
  PR.XNO39, PR.XNO55


Ejection PS

• PE.BSW12, PE.BSW14, PE.BSW20, PE.BSW22, PE.BSW23, PE.BSW31, PE.BSW57, PE.QKE16, PE.QKE25, PE.QKE73, PE.SMH16, PE.SMH57, PE.SMH61
